Description

Are you seeking top-of-the-line performance for your multirotor? Look no further than the Black Widow Series of motors, designed specifically for multi-rotor racing where only the best will do. These premium motor systems combine both the motor and ESC into a single unit, making them more compact, lighter, and more efficient. By integrating the motor and ESC into one unit, space is saved, the overall weight of the model is reduced, drag is minimized, and the system runs cooler.

The Black Widow motors feature a built-in ESC that enables you to change the direction of rotation of the motor with a simple flick of a switch. Additionally, there is a USB-compatible flash port at the base of the unit that allows you to update the firmware.

These sleek-looking motors are manufactured to exacting standards and use original NMB bearings for smooth running and reliable performance. Quality mounting accessories are included, and multiple mounting holes cater to most multi-rotor frames currently on the market.

If you’re into FPV racing and want motors with real bite in performance, then the Black Widow Series is your best choice.

Features:

All-in-one motor with built-in ESC

Built-in reversing switch

Built-in flashing port for firmware upgrades

Fast throttle response

High efficiency

CNC case for durability

0.2mm thickness silicon steel sheet used for stator which creates low current loss

NMB bearings for durability and smooth running

NdFeB high-temperature-rated magnets for trouble-free operation

Dynamically balanced

Compact and lightweight

Low internal resistance

All-in-one unit keeps wiring neat and tidy

Specs:

Model Name: 2204 18A

ESC Current: 18A

BEC Output: No

Firmware: BLHeli

ESC Battery cell: 2-3S Lipo

Motor KV: 2300KV

Direction: CW

Weight: 33.5g

Size: 27.5 x 19.4

Recommended prop size: 5-6″

Contents:

1 x ZTW Black Widow 2204 18A Motor With Integrated BLHeli ESC

1 x Manual
