Description

OVERVIEW

KV2300

Stator Diameter 22mm Rotor Diameter 27.4mm

Stator Thickness 5mm Body Length 18mm

No.of Stator Slots 12 Max Lipo Cell 3-4S

No.of Rotor Poles 14 ESC 30-45A

Motor Kv 2300 Recommended Prop(inch) GF5040*3/GF5045*3

No-load current 1.2A/10V

Motor Resistance 51.9mΩ

No-load current 40A/10s

Max Continuous Power 705W

Weight

31g

Prop(inch) Voltage(V) Throttle(%) Amps(A) Thrust(gf) Watts(W) Efficiency(g/W) Load temperature in 100% throttle

GF5040*3 14.8 1.2 100 18 5.63 8589 80℃ 60s

2.8 200 41 4.83 12405

4.8 300 71 4.22 15202

7.1 400 105 3.81 17717

9.7 500 144 3.48 19890

12.5 600 185 3.24 21649

15.4 700 228 3.07 23535

18.7 800 277 2.89 25050

22.5 900 333 2.70 26625

25.9 1002 383 2.61 28106

16.8 1.1 100 18 5.41 8707

2.5 200 42 4.76 12462

4.4 300 74 4.06 15265

6.5 400 109 3.66 17747

8.9 500 150 3.34 19896

11.4 600 192 3.13 21818

14.1 700 237 2.96 23505

16.9 800 284 2.82 24970

20.25 900 340 2.65 26687

23.6 1000 396 2.52 28240

30.8 1265 517 2.44 30813

GF5045*3 14.8 1.1 100 16 6.14 7741 89℃ HOT

2.7 200 40 5.01 10765

4.7 300 70 4.31 13151

7.1 400 105 3.81 15017

9.8 500 145 3.45 16793

12.8 600 189 3.17 18497

16.1 700 238 2.94 19974

19.5 800 289 2.77 21400

23.4 900 346 2.60 22734

28 1000 414 2.41 23901

33.5 1145 496 2.31 25404

16.8 1 100 17 5.95 7806

2.4 200 40 4.96 10704

4.3 300 72 4.15 13167

6.4 400 108 3.72 16818

8.8 500 148 3.38 16802

11.6 600 195 3.08 18492

14.7 700 247 2.83 1998

17.7 800 297 2.69 21395

21.1 900 354 2.54 22610

24.7 1000 415 2.41 23914

33.4 1200 561 2.14 26222

39.6 1386 665 2.08 27943
