Description

OVERVIEW

KV2300

Stator Diameter 22mm Rotor Diameter 27.4mm

Stator Thickness 4mm Body Length 16.5mm

No.of Stator Slots 12 Max Lipo Cell 3-4S

No.of Rotor Poles 14 ESC 25-30A

Motor Kv 2300 Recommended Prop(inch) GF5045*2/GF5040*3

No-load current 1.2A/10V

Motor Resistance 83mΩ

Max Continuous Current 25A/20s

Max Continuous Power 420W

Weight

27g

Prop(inch) Voltage(V) Throttle(%) Amps(A) Thrust(gf) Watts(W) Efficiency(g/W) Load temperature in 100% throttle

GF5045*2 14.8 1.2 100 18 5.63 9976 65℃

2.8 200 41 4.83 13680

4.8 300 71 4.22 16670

7.2 400 107 3.75 19110

9.9 500 147 3.41 21270

12.7 600 188 3.19 23328

16 700 237 2.96 25079

20.3 812 300 2.70 26818

16.8 1 100 17 5.95 9933

2.5 200 42 4.76 13554

4.3 300 72 4.15 16923

6.5 400 109 3.66 19133

9 500 151 3.31 21310

11.5 600 193 3.11 23216

14.4 700 242 2.89 24974

18 800 302 2.65 26417

24 960 403 2.38 28750

GF5040*3 14.8 1 100 15 6.76 8679 61℃ HOT

2.6 200 38 5.20 12188

4.7 300 70 4.31 15042

7.1 400 105 3.81 17627

9.9 500 147 3.41 19649

12.9 600 191 3.14 21482

16.2 700 240 2.92 23344

21.9 860 324 2.65 25638

16.8 0.9 100 15 6.61 8710

2.4 200 40 4.96 1227

4.2 300 71 4.25 15036

6.4 400 108 3.72 17358

9 500 151 3.31 19309

11.8 600 198 3.03 21556

14.5 700 244 2.87 23207

18 800 302 2.65 24826

21.8 900 366 2.46 26514

26 1030 437 2.36 28008
