Description

OVERVIEW

KV8000

Stator Diameter 11mm Weight 4g

Stator Thickness 2mm Rotor Diameter 14.2mm

No.of Stator Slots 9 Body Length 9.6mm

No.of Rotor Poles 12 Max Lipo Cell 2S

Motor Kv 8000 ESC 10-15A

No-load current 0.9A/10V Recommended Prop(inch) 2*3*3/3*2*2

Motor Resistance 240mΩ

Max Continuous Current 12A/30s

Max Continuous Power 89W

Prop(inch) Voltage(V) Amps(A) Thrust(gf) Watts(W) Efficiency(g/W) Load temperature in 100% throttle

2*3*3 7.4 1 25 7 3.38 32℃

2.3 50 17 2.94

3.9 75 29 2.60

5.2 90 38 2.34

3*2*2 7.4 0.8 25 6 4.22 35℃

2.2 50 16 3.07

3.9 75 29 2.60

5.7 100 42 2.37

7.5 122 56 2.20
