Description

Product Specifications:

Operating voltage: 3.8 – 8.4 volts (HV)

Case thickness: 8 mm

Housing width: 23.5 mm

Housing height: 16.6 mm

Weight: 8 g

Housing material: CNC-milled aluminum

Servo motor: Coreless bell anchor

Position sensor: Potentiometer

Positioning force:

14 Ncm at 3.8 volts

22 Ncm at 6.0 volts

28 Ncm at 8.4 volts

Adjustment time:

0.18 sec / 60° at 3.8 volts

0.15 sec / 60° at 6.0 volts

0.09 sec / 60° at 8.4 volts

Fastening straps: Included

Servo gear: Phosphor bronze + steel

Camp: Ball-bearing

Connection cable plug system: Approx. 15 cm Graupner connector

Package Contents:

1 Servo

3 Plastic servo arms

1 Servo arm screw

4 Fastening screws
