Description

This mini charger can charge up to four 1S single cell LiPo batterries at the same time with PH2.0 connector. Batteries with PH2.0 connectors include E-Flite mCPX, Tiny Whoop, and more.

Specification:

Brand: iSDT

Type: Charger

Input Type: USB Type-C

Input Voltage: 5-9V

Input Max Power: 18W

Output Max Voltage: 4.2V

Output current; 0.1A-1.5A/slot

Support battery: MCPX (4.2V), LiPo-1S*4

Meanings of UC4 indicator:

Red: Battery voltage over 4.4V or charge abnormality

Green: Fully charged

Orange with single blink: Normal charging with a capacity not more than 40%

Orange with two blinks: Normal charging with 40%-70% of the capacity

Orange with three blinks: Normal charging with 70%-99% of the capacity

Light off: No battery inserted.

Protection:

Over voltage protection

Over current protection

Overheat protection

Battery reversed polarity protection

Charge capacity limitation

Three indicators for charger current:

0.5A-white light indicator-single blink

1A-green light indicator-double blink

1.5A-green light indicator-three blinks

Packaging Included:

1X ISDT UC4 Charger
