Description

Features:

Independent detachable lens plug for FPV and visual observation flights

Wings with embedded carbon fiber rods at different angles

Compact wingspan with spacious electronics compartment

Four magnets for secure hatch fastening

Wingtip design for vertical take-off mode

Horizontal and vertical battery mounting options

Tailored lens ring for enhanced protection

New propeller locking method

Tailored for DJI Digital Air unit

Specifications:

Airplane dimensions: Wingspan 690mm, Height 88mm, Length 415mm

Fuselage space: Battery compartment 175mm x 175mm x 55mm

VTX fixed seat: Compatible with digital and analog VTX

KIT weight: 150g (EPP-30)/190g (EPP-20)

ESC compartment: 70mm x 38mm x 20mm

Materials: EPP/ABS/Carbon Fiber

Max Flight speed: ≥220km/h

Max Endurance: >70 minutes

Take-off weight: 350g – 850g

Min Flight speed: <27km/h Thrust: ≥920g (6 x 4E prop) Propeller: 5 x 5E/6 x 4E Max Mileage: >45km

Battery: 2S – 4S

Note: Lens cover recommended when speed is ≥100km/h to prevent excessive inflow air from blowing away the hatch.

PNP Youth Edition:

Motor: 2204-2200kv brushless x 1

ESC: FTC 20A brushless/2A UBEC build-in x 1

Propeller: 5045 x 2

Servo: digital 9g x 2

Hee Wing RX-1.0 flight controller x 1
